- Universal AC input voltage range
- Power will not de-rate for the entire input voltage range
- Power Boost of 150% for 3 seconds (24V/480W: 200% for 2 seconds)
- Full corrosion resistant aluminium casing (except 12V/15W, 12V/30w, 24V/48W and 24V/80W)
- Conformal coating on PCBAs to protect against common dust and chemical pollutants (except DRP-24V48W1AZ and DRP024V06W1AZ)
- Hazardous Locations approval to ATEX and class I, Div 2 for selected models
| Model Name |
Phase |
PFC |
Output Voltage |
Output Current |
Output Power |
Input Voltage Range |
Dimensions (L x W x H) |
Download datasheet |
| DRP012V015W1AY |
Phase I |
|
12V |
1.25A |
15W |
85-264Vac |
100 x 32 x 100.6 mm |
|
| DRP012V015W1AZ |
Phase I |
|
12V |
1.25A |
15W |
85-264Vac |
100 x 32 x 100.6 mm |
|
| DRP012V030W1AY |
Phase I |
|
12V |
2.50A |
30W |
85-264Vac |
100 x 32 x 100.6 mm |
|
| DRP012V030W1AZ |
Phase I |
|
12V |
2.50A |
30W |
85-264Vac |
100 x 32 x 100.6 mm |
|
