- International AC voltage options
- Up to 94.0% efficiency
- 6kV common mode & 4kV differential mode surge immunity
- Active PFC. Meets IEC/EN 61000-3-2, Class C
- 3-in-one-dimming of output current: By resistor, 1 -10 VDC or 10V PWM
- IP67 assembly for indoor and outdoor applications
| Model Name |
Phase |
PFC |
Output Voltage |
Output Current |
Output Power |
Input Voltage Range |
Dimensions (L x W x H) |
Download datasheet |
| LNE-12V320WACA |
Phase I |
|
12V |
22.5A |
270W |
90-264Vac |
252 x 90 x 43.8 mm |
|
| LNE-36V600WBGA |
Phase I |
|
36V |
16.7A |
601.2W |
100-277Vac |
307.5 x 114.3 x 50.8 mm |
|
| LNE-48V600WBGA |
Phase I |
|
48V |
12.5A |
600W |
100-277Vac |
307.5 x 114.3 x 50.8 mm |
|
