Force-GT series
DRF-24V240W3GBA
Universal AC input voltage range. Built-in constant current circuit for charging applications. Full load operating temperature up to 60°C. Cold start at -40°C. Ultra-Slim design. Long life electrolytic capacitor. Built-in DC OK relay and LED indicator. Conformal coating on PCBAs to protect against common dust and pollutants.
Main specifications DRF-24V240W3GBA:
Input Voltage Range: 3 x 320-575 Vac (3-Phase) or 2 x 340-575 Vac (2-Phase)
Input Frequency Range: 47-63Hz
Output Voltage Adjustment Range: 24-28Vdc
Output Current: 10A
Output Power: 240W
Dimensions (LxWxD): 124 x 50 x 125.3 mm (4.88” x 1.97” x 4.93”)
Unit Weight: 0.84 kg (1.85 lb)
