- Wide range AC input (90-264Vac)
- 3rd edition Medical and ITE safety approvals
- 2 x MOPP (means of patient protection)
- Leakage current (<0.1mA)
- Engergy Star Level VI
- plug in AC inlets and DIN or barrel type output connectors
- IP22 compliance
- Compact size
- Standby power <0.3W
- 3 years warrenty
| Model Name |
Phase |
PFC |
Output Voltage |
Output Current |
Output Power |
Input Voltage Range |
Dimensions (L x W x H) |
Download datasheet |
| MDS-030AAC05 |
Phase I |
|
5V |
3A |
15W |
85-264Vac |
88 x 53.5 x 27.5 mm |
|
| MDS-030AAC12 |
Phase I |
|
12V |
2A |
24W |
85-264Vac |
88 x 53.5 x 27.5 mm |
|
| MDS-030AAC15 |
Phase I |
|
15V |
2A |
30W |
85-264Vac |
88 x 53.5 x 27.5 mm |
|
| MDS-030AAC24 |
Phase I |
|
24V |
1.25A |
30W |
85-264Vac |
88 x 53.5 x 27.5 mm |
|
