  • International AC voltage options
  • Up to 94.0% efficiency
  • 6kV common mode & 4kV differential mode surge immunity
  • Active PFC. Meets IEC/EN 61000-3-2, Class C
  • Adjustable voltage & current: By potentiometers
  • IP65 assembly for indoor and outdoor applications



lne

Model Name Phase PFC Output Voltage Output Current Output Power Input Voltage Range Dimensions (L x W x H) Download datasheet
LNE-12V320WACA Phase I 12V 22.5A 270W 90-264Vac 252 x 90 x 43.8 mm
LNE-24V320WACA Phase I 24V 13.34A 320W 90-264Vac 252 x 90 x 43.8 mm
LNE-36V320WACA Phase I 36V 8.9A 320W 90-264Vac 252 x 90 x 43.8 mm
LNE-48V320WACA Phase I 48V 6.7A 320W 90-264Vac 252 x 90 x 43.8 mm
