DRF-12V240W1GBA

Universal AC input voltage range. Built-in constant current circuit for charging applications. Full load operating temperature up to 60°C. Cold start at -40°C. Ultra-Slim design. Long life electrolytic capacitor. Built-in DC OK relay and LED indicator. Conformal coating on PCBAs to protect against common dust and pollutants.



Main specifications DRF-12V240W1GBA:

Input Voltage Range: 90-264Vac

Input Frequency Range: 47-63Hz

Output Voltage Adjustment Range: 12-14Vdc

Output Current: 20A

Output Power: 240W

Dimensions (LxWxD): 123.6 x 40 x 116.8 mm (4.87” x 1.57” x 4.60”)

Unit Weight: 0.64 kg (1.41 lb)
