- Universal AC voltage range
- Full corrosion resistant aluminium casing
- Built-in active PFC and conforms to harmonic current IEC/EN 61000-3-2, Class A and Class D
- Low profile design for 1U installation
- Built-in DC OK relay contact and redundancy operation
| Model Name |
Phase |
PFC |
Output Voltage |
Output Current |
Output Power |
Input Voltage Range |
Dimensions (L x W x H) |
Download datasheet |
| PMR-12V150W1AT |
Phase I |
|
12V |
12.5A |
150W |
90-264Vac |
129 x 97 x 30 mm |
|
| PMR-12V240W1AT |
Phase I |
|
12V |
20A |
240W |
90-264Vac |
159 x 97 x 30 mm |
|
| PMR-12V320W1AT |
Phase I |
|
12V |
26.7A |
320W |
90-264Vac |
215 x 115 x 30 mm |
|
| PMR-12V600W1BT |
Phase I |
|
12V |
50A |
600W |
90-264Vac |
225 x 124 x 41 mm |
|
| PMR-24V150W1AT |
Phase I |
|
24V |
6.5A |
150W |
90-264Vac |
129 x 97 x 30 mm |
|
| PMR-24V240W1AT |
Phase I |
|
24V |
10A |
240W |
90-264Vac |
159 x 97 x 30 mm |
|
| PMR-24V320W1AT |
Phase I |
|
24V |
13.4A |
320W |
90-264Vac |
215 x 115 x 30 mm |
|
| PMR-24V600W1BT |
Phase I |
|
24V |
25A |
600W |
90-264Vac |
225 x 124 x 41 mm |
|
| PMR-36V150W1AT |
Phase I |
|
36V |
4.3A |
150W |
90-264Vac |
129 x 97 x 30 mm |
|
| PMR-36V240W1AT |
Phase I |
|
36V |
6.7A |
240W |
90-264Vac |
159 x 97 x 30 mm |
|
| PMR-36V320W1AT |
Phase I |
|
36V |
8.9A |
320W |
90-264Vac |
215 x 115 x 30 mm |
|
| PMR-36V600W1BT |
Phase I |
|
36V |
16.6A |
600W |
90-264Vac |
225 x 124 x 41 mm |
|
| PMR-48V150W1AT |
Phase I |
|
48V |
3.3A |
150W |
90-264Vac |
129 x 97 x 30 mm |
|
| PMR-48V240W1AT |
Phase I |
|
48V |
5A |
240W |
90-264Vac |
159 x 97 x 30 mm |
|
| PMR-48V320W1AT |
Phase I |
|
48V |
6.7A |
320W |
90-264Vac |
215 x 115 x 30 mm |
|
| PMR-48V600W1BT |
Phase I |
|
48V |
12.5A |
600W |
90-264Vac |
225 x 124 x 41 mm |
|
