- Constant current design
- Input voltage from 198-264Vac
- Up to 90.5% efficiency
- Independent or built-in type
- Meets IEC/EN 61000-3-2, Class C
- Fixed output current
- IP20 assembly for indoor applications
| Model Name |
Phase |
PFC |
Output Voltage |
Output Current |
Output Power |
Input Voltage Range |
Dimensions (L x W x H) |
Download datasheet |
| EUCI-020070GLA |
Phase I |
|
24-54V |
0.7A |
20W |
198-264Vac |
147.0 x 43.0 x 30.0 mm |
|
| EUCI-022105GLB |
Phase I |
|
8-48V |
0.2-1.05A |
22W |
198-264Vac |
133 x 77 x 40 mm |
|
| EUCI-040105GLA |
Phase I |
|
|
1.05A |
40W |
198-264Vac |
133 x 77 x 40 mm |
|
| EUCI-040105GLB |
Phase I |
|
20-77V |
0.2-1.05A |
40W |
198-264Vac |
133 x 77 x 40 mm |
|
| EUCI-075105GLA |
Phase I |
|
|
1.05A |
75W |
198-264Vac |
133 x 77 x 40 mm |
|
| EUCI-130105GLA |
Phase I |
|
|
1.05A |
130W |
198-264Vac |
150 x 90 x 40 mm |
|
| EUCI-170105GLA |
Phase I |
|
|
1.05A |
170W |
198-264Vac |
170 x 100 x 40 mm |
|
