- Minimum buffering time of:
250ms @ 24V/20A for DRB-24V020AB
200ms @ 24V/20A for DRB-24V040ABN
- Flexible operating buffering voltage modes -
Fixed mode at 22Vdc; Dynamic mode for V -1V
- Support parallel connectrion to extend buffering time
- Conformal coating on PCBs to protect against common dust and chemical pollutants
- Hazadous Locations approval to ATEX and Class 1, Div 2 for DRB-24V020ABA
| Model Name |
Phase |
PFC |
Output Voltage |
Output Current |
Output Power |
Input Voltage Range |
Dimensions (L x W x H) |
Download datasheet |
| DRB-24V020ABA |
Phase I |
|
24V |
20.0A |
0.6A |
22.8-28.8Vdc |
121 x 70 x 120.1 mm |
|
| DRB-24V020ABN |
Phase I |
|
24V |
20.0A |
0.6A |
22.8-28.8Vdc |
121 x 70 x 120.1 mm |
|
| DRB-24V040ABN |
Phase I |
|
24V |
40.0A |
0.6A |
22.8-28.8Vdc |
121 x 70 x 120.1 mm |
|
