- Safety Approvals to IEC 60601-1 3.1rd ed. & IEC 60950-1
- Compliant with IEC 60601-1-2 4th Ed. Requirements
- Low touch current (<0.1mA Normal & <0.3mA single fault)
- Over-Voltage/Load/Temperature & Short Circuit protections
- 3 Million Hours MTBF
- 2 x MOPP (means of patient protection)
- 3 years warranty
| Model Name |
Phase |
PFC |
Output Voltage |
Output Current |
Output Power |
Input Voltage Range |
Dimensions (L x W x H) |
Download datasheet |
| MEP-120A12J |
Phase I |
|
12V |
9.5A |
114W |
90-264Vac |
76.2 x 50.8 x 31 mm |
|
| MEP-120A15J |
Phase I |
|
15V |
8A |
120W |
90-264Vac |
76.2 x 50.8 x 31 mm |
|
| MEP-120A18J |
Phase I |
|
18V |
6.67A |
120W |
90-264Vac |
76.2 x 50.8 x 31 mm |
|
| MEP-120A24J |
Phase I |
|
24V |
5A |
120W |
90-264Vac |
76.2 x 50.8 x 31 mm |
|
