- Universal AC input voltage range
- Zero switch over time from loss of AC to battery operation
- Protection against reverse polarity battery connection
- Built-in diagnostic monitoring for AC OK and Battery Low status
- Overvoltage / Overcurrent / Over Temperature / Short circuit Protections
- Built-in over current and short circuit protection in Buffering (battery discharging) mode operation
| Model Name |
Phase |
PFC |
Output Voltage |
Output Current |
Output Power |
Input Voltage Range |
Dimensions (L x W x H) |
Download datasheet |
| PJU-13V60WCBA |
Phase I |
|
13.8V |
4.3A |
60W |
90-264Vac |
103.4 x 62 x 37 mm |
|
| PJU-27V60WCBA |
Phase I |
|
27.6V |
2.15A |
60W |
100-240Vac |
103.4 x 62 x 37 mm |
|
