- Suitable for 24V system up to 40A
- Built-in diagonstic monitoring for DC OK, Discharge and Battery Fail by relay contacts
- LED indicator DC OK, Battery Fail, DC Input, Battery Reverse Polarity and Battery Discharge
- High MTBF > 500,000 hrs per Telcordia SR-332
- Conformal coating on PCBs to protect against common dust and chemical pollutants
- Overvoltage / Overcurrent / Over temperature / Short circuit protections
| Model Name |
Phase |
PFC |
Output Voltage |
Output Current |
Output Power |
Input Voltage Range |
Dimensions (L x W x H) |
Download datasheet |
| DRU-24V10ACZ |
|
|
24V |
10.0A |
240W Max |
24-28Vdc |
91.0 x 71.0 x 55.6 mm |
|
| DRU-24V10AMN |
Phase I |
|
24V |
10A |
240W |
18-30 Vdc |
124 x 38 x 117 mm |
|
| DRU-24V20AMN |
Phase I |
|
24V |
20A |
480W |
18-30 Vdc |
124 x 38 x 117 mm |
|
| DRU-24V40ABN |
|
|
24V |
40.0A |
960W Max |
23-28Vdc |
121 x 50 x 117.3 mm |
|
| DRU-24V40AMN |
Phase I |
|
24V |
40A |
960W |
18-30 Vdc |
124 x 50 x 117 mm |
|
