Force-GT series - Switch-Mode

Model Name	Phase	Output Voltage	Output Current	Output Power	Input Voltage Range	Dimensions (L x W x H)
DRF-12V120W1GBA	Phase I	12V	10A	120W	90-264Vac	123.6 x 30 x 116.8 mm
DRF-12V240W1GBA	Phase I	12V	20A	240W	90-264Vac	123.6 x 40 x 116.8 mm 4.87” x 1.57” x 4.60”
DRF-24V120W1GBA	Phase I	24V	5A	120W	90-264Vac	123.6 x 30 x 116.8 mm
DRF-24V120W3GBA	Phase I	24V	5A	120W	3 x 320-575 Vac (3-Phase) or 2 x 340-575 Vac (2-Phase)	124 x 38 x 125.3 mm
DRF-24V240W1GBA	Phase I	24V	10A	240W	90-264Vac	123.6 x 40 x 116.8 mm
DRF-24V240W3GBA	Phase I	24V	10A	240W	3 x 320-575 Vac (3-Phase) or 2 x 340-575 Vac (2-Phase)	124 x 50 x 125.3 mm
DRF-24V480W1GBA	Phase I	24V	20A	480W	90-264Vac	123.6 x 56 x 116.8 mm
DRF-24V480W3GBA	Phase I	24V	20A	480W	3 x 320-575 Vac (3-Phase) or 2 x 340-575 Vac (2-Phase)	124 x 65 x 127.3 mm
DRF-24V960W3GBA	Phase I	24V	40A	960W	3 x 320-575 Vac (3-Phase) or 2 x 340-575 Vac (2-Phase)	124 x 110 x 128.7 mm
DRF-48V120W1GBA	Phase I	48V	2.5A	120W	90-264Vac	123.6 x 30 x 116.8 mm
DRF-48V240W1GBA	Phase I	48V	5A	240W	90-264Vac	123.6 x 40 x 116.8 mm
DRF-48V480W1GBA	Phase I	48V	10A	480W	90-264Vac	123.6 x 56 x 116.8 mm
