Delta medical and industrial external series

Wide range AC input (90-264Vac)
3rd edition Medical and ITE safety approvals
2 x MOPP (means of patient protection)
Leakage current (<0.1mA)
Engergy Star Level VI
Available C14. C8 and C6 3-pin AC inlets and DIN or barrel type output connectors
IP22 compliance
Compact size
Standby power <0.3W
3 years warrenty

medical external

Model Name	Phase	Output Voltage	Output Current	Output Power	Input Voltage Range	Dimensions (L x W x H)
MDS-150CAB19 A	Phase I	19V	7.90A	150W	90-264Vac / 47-63Hz	2.5" x 5.9" x 1.2"
MEA-065A12B	Phase I	12V	5A	60W	90-264Vac	120 x 50 x 32 mm
MEA-065A12C	Phase I	12V	5A	60W	90-264Vac	50 x 115 x 29 mm
MEA-065A15B	Phase I	15V	4.33A	65W	90-264Vac	120 x 50 x 32 mm
MEA-065A15C	Phase I	15V	4.33A	65W	90-264Vac	50 x 115 x 29 mm
MEA-065A19B	Phase I	19V	3.42A	65W	90-264Vac	120 x 50 x 32 mm
MEA-065A19C	Phase I	19V	3.42A	65W	90-264Vac	50 x 115 x 29 mm
MEA-065A24B	Phase I	24V	2.71A	65W	90-264Vac	120 x 50 x 32 mm
MEA-065A24C	Phase I	24V	2.71A	65W	90-264Vac	50 x 115 x 29 mm
MEA-090A12C	Phase I	12V	6.75A	81W	90-264Vac / 47-63Hz	5.31” x 2.44” x 1.26”
MEA-090A15C	Phase I	15V	6A	90W	90-264Vac	135 x 62 x 32 mm
MEA-090A19C	Phase I	19V	4.74A	90W	90-264Vac	135 x 62 x 32 mm
MEA-090A24C	Phase I	24V	3.75A	90W	90-264Vac	135 x 62 x 32 mm
MEA-160A12C	Phase I	12V	12.5A	150W	85-264Vac	150 x 65 x 32 mm
MEA-160A15C	Phase I	15V	10.67A	160W	85-264Vac	150 x 65 x 32 mm
MEA-160A19C	Phase I	19V	8.42A	160W	85-264Vac	150 x 65 x 32 mm
MEA-160A24C	Phase I	24V	6.67A	160W	85-264Vac	150 x 65 x 32 mm
MEA-250A24C	Phase I	24V	10.42A	250W	90-264Vac / 47-63Hz	7.87" x 3.94" x 1.69"
